Overview

This Information Bulletin has been prepared to provide a common understanding of the Draft Terms of Reference (ToR) for the East-West Corridor Light Rail Transit (LRT) Project: Environmental Assessment. It includes information on the proposed project and the Draft ToR which sets out a framework that will guide the preparation of the Environmental Assessment (EA).

Project Background

The proposed East-West Corridor LRT Project

was developed at a strategic level through the Rapid Transit Expansion Study (RTES), 2003. Following on from RTES, the Ottawa Rapid Transit Expansion Program (ORTEP) Implementation Strategy identified the immediate undertaking of the planning work for the North-South and East-West LRT projects as critical to meet the implementation timeframe for light rail projects.

In the spring of 2004, the Statement of Work for the East-West Corridor LRT Project: Environmental Assessment (EA) Study was approved by the City's Transportation Committee.

This Study will examine a range of alternatives, identify both construction and operational impacts on all aspects of the environment and bring forward a recommended plan detailing mitigation measures, costs, and all approvals required to proceed with implementation as opportunities present themselves. The Study will be conducted in accordance with both Provincial and Federal Environmental Assessment Act requirements. The first step in the assessment process is the development of a ToR which requires Ministry of the Environment (MOE) approval.

Study Area

The proposed East-West Corridor LRT Project is approximately 47 km long, spanning from Orléans to Kanata. The rapid transit corridor would provide improved east-west transit connectivity bypassing the downtown. It also presents a unique opportunity to influence developments within the growth areas of Kanata and Orléans as well as inside the Greenbelt.

The study area is characterized as a corridor encompassing both sides of the existing rail corridor. In the east end, the band is narrower as the alignment has been defined by earlier studies. Along most of the corridor, it is wide enough to consider potential parallel corridors such as arterial roads and hydro corridors. In Kanata, the study area widens out to consider several route options, which will be evaluated to determine which best serves the existing and future growth.

Schedule

The proposed schedule for the EA Study (including legislated review periods) is as follows:

! Submit Terms of Reference to MOE in January 2005.

! Anticipated MOE approval of the ToR by April 2005 (12 weeks after submission). This includes a 30-day public and agency review and allows for review and approval by MOE .

! Submit completed EA Report to MOE by May 2006, including documentation of all public consultation and all relevant transportation and environmental planning studies undertaken during the course of the study.

! MOE approval is anticipated by December 2006. This is based on legislation providing up to 30 weeks for review and approval.

Terms of Reference

The ToR is a document which sets out a framework to guide the preparation of an Individual EA. The City of Ottawa must submit the ToR to the Ministry of the Environment for approval. The approved ToR is the first statutory decision by the MOE in the EA planning and approval process. The ToR describes:

! The Proposed Project Purpose

! Environmental Assessment Work Plan

! Environmental Assessment Consultation Plan

! Additional Approvals Required

Purpose of the Undertaking

The preliminary rationale for the undertaking is twofold:

! Help to satisfy the study area transportation demand and to achieve the City wide transit modal split target of 30% (i.e., solving the problem); and

! To protect land for the transit facility in advance of major development (i.e., opportunity to establish and plan for appropriate development densities and create transit-oriented developments (TODs) around the facility and stations).

Environmental Assessment Work Plan

The EA Work Plan includes the following major activities:

Purpose/Need: This activity will be undertaken to document the purpose and rationale for the undertaking. A Ridership Study will be completed as part of this activity.

Existing Conditions: Existing biological, physical, economic, social and technical environmental conditions will be documented as a baseline against which to assess and evaluate the potential effects of the alternatives on the environment.

Alternatives: Alternatives to the undertaking (do nothing, widen roads, rapid transit, combinations of road and transit) and alternatives ways to carry out the undertaking (technologies, corridors, station locations, infrastructure) will be identified and evaluated.

Assessment & Evaluation: Various assessment and evaluations methods will be developed and used to select the preferred alternative.

Environmental Assessment Consultation Plan

Consultation will include two invited Consultation Groups and Public Participation at Open Houses at key points during the study.

Public Consultation Group (PCG): formed to enable the community and interest groups to provide direct input into the study. It includes representatives from City Wards adjacent to the corridor, interest groups, and representatives from several City advisory committees.

Agency Consultation Group (ACG): formed to address the full range of technical issues and to comment on special studies as well as applicable procedures and legislation and policies. The ACG includes representatives from all levels of government.

Three Open Houses are planned for the Study:

! EA Open House #1 (Spring 2005)

! EA Open House #2 (Fall 2005)

! EA Open House #3 (Spring 2006)

City’s Website: Information on the EA will be available on the City’s website www.ottawa.ca/lrt

Additional Approvals

Additional approvals may be required beyond the Federal and Provincial Environmental Assessment Acts. The City of Ottawa is committed to obtaining the necessary approvals at the appropriate time in the implementation phase. The agencies responsible for issuing approvals will be consulted during the EA to address their interests and approval requirements.

Next Steps

Following this Open House, the Study Team will:

! Incorporate your comments into the draft ToR.

! Present the revised ToR to Transportation Committee and Council.

! Incorporate Committee and Council comments into the Final ToR.

! Submit the Final ToR to MOE for approval.

The MOE approved ToR will provide the framework for completing the Individual Environmental Assessment. When reviewing the EA, the MOE will ensure that the EA followed the process as set out in the ToR.

Before you leave tonight, please complete the Comment-Questionnaire and place it in the designated box, or mail or fax it to us by December 17, 2004.

Questions or Comments

If you have any questions or comments

about the study, please contact:

Mona Abouhenidy, Ph.D., P.Eng.

Planning and Growth Management Department

City of Ottawa

110 Laurier Avenue West, 4^th Floor

Telephone: 580‑2424, ext. 26936

Fax: 580-2578

E-mail: mona.abouhenidy@ottawa.ca

Prepared by Delcan Corporation

Terms of Reference Public Open House

November/December 2004
